simple tilt front leg, 10 DEG, aluminium, stainless steel

Product Description:

Maximize the stability and aesthetics of your solar panel installation with the SnapNrack UR-40 Rail, specially designed for seamless integration into any solar system. This 172-inch long rail, finished in elegant black, is crafted from high-strength 6000 series aluminum, ensuring both durability and a sleek appearance. Certified under UL 2703 for safety and performance, the UR-40 rail is an essential component for any residential or commercial solar setup.

Key Features:

• Durable Material: Made from 6000 series aluminum for superior strength and longevity.

• Sleek Black Finish: Offers an aesthetically pleasing look that complements a variety of solar panel styles and home exteriors.

• Certified Safety: UL 2703 certification ensures compliance with safety standards, providing peace of mind in structural integrity.

• Versatile Compatibility: Designed to support a variety of solar panel sizes and weights, facilitating a broad range of installation needs.

Technical Specifications:

• Material: 6000 series aluminum

• Length: 172 inches

• Finish: Black

• Weight: Between 5.85 to 5.99 lbs

• Certification: UL 2703

Installation and Use:

• Ease of Installation: The rail is designed for easy integration with standard solar mounting systems, making setup quick and efficient.

• Structural Properties: Features excellent section properties like a moment of inertia (Ixx 0.125 in⁴ and Iyy 0.132 in⁴) and section modulus (Sx top 0.150 in³, Sx bottom 0.158 in³), ensuring robust support and load distribution.

Enhance the durability and aesthetic of your solar installation with the SnapNrack UR-40 Rail, combining functionality with a stylish finish to elevate your renewable energy solutions.

Keywords:

SnapNrack UR-40 Rail, solar panel rail, black aluminum rail, UL certified solar component, durable solar mounting system, residential solar rail, commercial solar installation, long solar panel rail, stylish solar mount, SnapNrack solar solutions.

Manufacturer SnapNrack

Manufacturer Item Type Name Ultra Rail Simple Tilt Front Leg

Height without packaging (mm) 115.06

Width without packaging (mm) 38.1

Weight (kg) 0.18

Color silver
